Fusion Series
The revolutionary Fusion series amplifiers deliver the ultimate audio experience for discerning audiophiles who crave both the nuanced fidelity of stereo music and the explosive power and speed demanded by cinematic experiences.
At the heart of this groundbreaking amplifier lies a unique integration of power supply and Class-D amplifier circuit, seamlessly blending the precision and clarity essential for stereo music playback with the dynamic range and impact required for immersive movie watching.
The Fusion amplifier optimizes every aspect of audio reproduction, from the subtlest musical nuances to the thunderous impact of cinematic sound effects, ensuring a truly captivating auditory journey. With its ability to effortlessly transition between the delicate intricacies of stereo music and the adrenaline-fueled dynamics of blockbuster movies, audiophiles no longer have to make compromise or have two different systems.
Features
- The Fusion amplifiers work at frequencies 700KHz. This innovation cuts down the MOSFET's temperature by 30%, conserves energy, and maintains a cool operation even at full throttle, ensuring consistent sound quality.
- Fusion Class-D module delivers unparalleled accuracy and minimal distortion (measured value minimum 0.004% @ 5W). It features a dedicated power supply for each channel, complete with six 2200uF capacitors and a 15A-grade high-frequency filter, effectively reducing power noise and channel crosstalk.
- The system boasts a robust and swift power delivery, with capacitors directly integrated into the amplification circuit. This setup provides a surge of energy on demand, catering to the dynamic requirements of contemporary audio-visual content.
- Capable of delivering 500W at 8Ω and 500W at 4Ω, the amplifier can power speakers with an impedance as low as 3 ohms and can briefly sustain loads down to 2 ohms.
- Each channel is equipped with its own cutting-edge protection circuit, which instantly disconnects the speaker output to safeguard against any irregularities in the device.
- The fully balanced input circuitry significantly diminishes noise and interference, ensuring pristine signal quality over extended distances.
- The amplifier uses an advanced ultra-low noise power module. The power module and the Class D module have specially customized metal modules that can isolate the system power from external electromagnetic interference and prevent any mechanical humming noise.
Specifications
- Power Output (RMS rated) @ 4 Ohm: 500 W
- Power Output (RMS rated) @ 8 Ohm: 500 W
- Gain (factor): Min 17X, Max 25X
- Sensitivity (to rated power): 2 Vrms Input
- Impedance: 47K Ohm
- THD + N: 0.007@5W 1K Hz, 0.012@50W 1K Hz, 0.02@100W 1K Hz
- Frequency Response: 10Hz ~ 50K Hz
- Signal to Noise Ratio: 100 dB @ 10W, 110 dB @ 100W
